Ultimate 2-pc 3D Carving Taper Ball Nose Bit Set For CNC Routers, 1/4 Shank

Save $5 when you get this set of precision-engineered 3D carving taper ball nose bits by IDC Woodcraft. They are designed to provide the highest level of detail on your 3D woodworking carves, enabling you to tackle any project, from delicate and intricate designs to larger, more complex 3D carvings.

$49.97 USD

Availability: In Stock

Quantity:

Add another popular bit to your cart!

Description

The IDC Woodcraft 3D carving taper ball nose bit set for CNC routers are the ultimate CNC router bits for achieving fine-detail and ultra-fine detail 3D carving.

Sometimes called 'bullnose bits', these bits are precision-engineered to provide the highest level of accuracy and control. The set includes both a fine-detail taper ball nose bit and an ultra-fine detail taper ball nose bit, enabling you to tackle any project, from delicate and intricate designs to larger, more complex carvings.

The taper ball nose design allows for smooth and precise cuts, making it easy to achieve stunning results. Whether you're a professional woodworker or a hobbyist CNC router owner, this bit set is a must-have for any CNC router. Upgrade your woodworking game and achieve fine-detail and ultra-fine detail 3D carving with the IDC Woodcraft 3D carving taper ball nose bit set.

The broad 10° angle significantly reduces tip deflection common with narrow steep angle taper ball nose bits, such as 6°, 5°, or less. Tip deflection can deform the fine details of your 3D carve, making them look 'not quite right'.

Also known as a 'carving bit', the tip/angle combination is able to hold the fine detail in your 3D carves extremely well, while keeping the run time down.

Every CNC'er wants to make awesome 3D carves. To learn how to set up 3d carves, watch this video.

TBN-SET

Fine-Detail Taper Ball Nose Bit (TBN-1)

Specs: for this CNC router bit.

  • Shank: 1/4" (6.35mm)
  • Flutes: 2
  • Length: 2" (60mm)
  • Side-Angle: 10 degrees (full angle 20°)
  • Ball nose radius 0.045" (3/64) (1.14mm)
  • Material: Tungsten carbide

Settings

  • Feed rate: 60 inches per minute
  • Plunge rate: 25 inches per minute
  • Speed(rpm): 19,000
  • Depth per pass: 0.250"
  • Stepover: 6-8%

Fine-Detail Taper Ball Nose Bit (TBN-2)

  • Shank: 1/4" (6.35mm)
  • Flutes: 2
  • Length: 2.25" (60mm)
  • Side-Angle: 10 degrees (full angle 20°)
  • Ball nose radius 0.045" (3/64) (1.14mm)
  • Material: Tungsten carbide

Settings for your CNC router

  • Plunge rate: 20 ipm
  • Feed rate: 60-80 in/m (35-47mm/s)
  • Stepover: 6-8%
  • RPM: 14,000-18,000

For Vectric users, get the latest CNC router bit tool database by going to this page

For CNC’s with routers, refer to this PDF download feeds & speeds table
