Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
tapered ball nose end mill for detailed 3d router bit cnc carves
Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
tapered ball nose end mill for detailed 3d router bit cnc carves
tapered ball nose end mill for detailed 3d router bit cnc carves
tapered ball nose end mill for detailed 3d router bit cnc carves
tapered ball nose end mill for detailed 3d router bit cnc carves
Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
tapered ball nose end mill for detailed 3d router bit cnc carves
Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
tapered ball nose end mill for detailed 3d router bit cnc carves
tapered ball nose end mill for detailed 3d router bit cnc carves
tapered ball nose end mill for detailed 3d router bit cnc carves
tapered ball nose end mill for detailed 3d router bit cnc carves

Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank

Availability: In Stock

$27.94 USD

Quantity:

This bit is excellent for almost any size 3D carve. The benefit...it saves time while still holding great detail in your CNC woodworking 3D projects.

The taper ball nose endmill is the most common router bit for CNC routers when designing finely detailed 3D carvings on your CNC router. The broader 10° angle significantly reduces tip deflection common on shallower angled bits. Also known as a 'carving bit', the 0.09" diameter tip carves your detail while keeping the run time down.

Specs:

  • Shank: 1/4" (6.35mm), Flutes: 2, Length: 2.375" (55mm), Angle: 10 degrees
  • Ball nose radius: 0.045" (1.143 mm), Feed rate setting: 80-120 in/m (35-47mm/s), RPM: 14,000-18,000

Enhance Your Carve

Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank

Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank

$27.94 USD

Add this item

+

Ultra-High Detail 3D Carving Taper Ball Nose Bit For CNC Routers, 1/4 Shank

Ultra-High Detail 3D Carving Taper Ball Nose Bit For CNC Routers, 1/4 Shank

$27.94 USD

Add this item

+

The HOG 1/4" Roughing Endmill Bit For CNC Routers, 1/4" Shank

The HOG 1/4" Roughing Endmill Bit For CNC Routers, 1/4" Shank

$45.43 USD

Add this item

Key Details

Feeds And Speeds

Reviews

When it comes to bits for 3D carving, the fine detail 3D carving bit, also known as a taper ball nose endmill, is the most common router bit for fine detail 3D projects on a CNC router.

This bit is excellent for almost any size 3D carve. Th benefit...it saves time while still holding great detail in your CNC woodworking 3D projects.

The broader 10° angle significantly reduces tip deflection common on shallower angled bits, such as 6°, 5°, or less. Tip deflection can deform the fine details of your 3D carve, making the look 'not quite right'.

Also known as a 'carving bit', the fine detail 3D carving bits 0.07" diameter tip is able to hold the fine detail in your 3D carves extremely well, while keeping the run time down.

Every CNC'er wants to make awesome 3d carves. The fine detail 3D carving bit is the bit to start with. To learn how to set up 3d carves, watch this video.

Item SKU: TBN-2

Specs: for this CNC router bit.

  • Shank: 1/4" (6.35mm)
  • Flutes: 2
  • Length: 2.2" (60mm)
  • Side-Angle: 10 degrees (full angle 20°)
  • Ball nose radius 0.045" (3/64) (1.14mm)
  • Material: Tungsten carbide

Settings

  • Feed rate: 60 inches per minute
  • Plunge rate: 25 inches per minute
  • Speed(rpm): 19,000
  • Depth per pass: 0.250"
  • Stepover: 6-8%

For Vectric users, get the latest CNC router bit tool database by going to this page

For CNC’s with routers, refer to this PDF download feeds & speeds table

Get feeds and speeds in your shop by scanning this QR code with the IDC Woodcraft App!

Customer Reviews

Based on 23 reviews
96%
(22)
4%
(1)
0%
(0)
0%
(0)
0%
(0)
D
Dennis Donovan

My router is not working so I am unable to let you know on either of the bits that I purchased.Sorry.

T
Timmy

I enjoy all the bits I bought from you. They’ve been excellent.

T
Thomas Melinn
3D bit

I did my first successful 3D carve with this bit. It turned out great!

D
Danny Ramsey
Fine detail carving bit

So far this is a superb bit, I tried the design offered for free and the results were amazing! Even under magnifying glass no errors were noted.

M
Mick Weber

Fine Detail 3D Carving Bit For CNC Routers, 1/4" Shank
