60 Degree V Grooving Bit for CNC Routers, 1/4 Shank

The 60 degree v bit 'Super Shear' for CNC routers is the bit when speed matters as much as the carving quality. This 60 degree bit is part of the Big Stiffy series, a set of bits designed to virtually eliminate uneven carves due to chatter. See full description for more info.

  • Shank: 1/4" / Length: 2" / Flutes: 2 / Flute length: 0.65" / Cut Dia. 3/4"
  • Cut angle 60 degree / 100% carbide

$34.92 USD

Availability: In Stock

Quantity:

Key Details

Feeds And Speeds

Reviews

The Big Stiffy series 60-degree v-bit for CNC routers is larger, and cuts deeper, than the typical 60 deg v bit. The extra body size lets you maximize your carve time while also leaving a clean cut.

With a 1/4" shank, it is the go-to 60 deg carving v-bit for home-based CNC'ers when it comes to larger projects when you are large v carves and chamfers on your CNC router woodworking projects. The 'super-shear' blade design is designed to leave exceptionally clean cuts at higher feed rates. This is the v bit to use when your v-carved letters are wider than 1/4" wide.

To see how effective your Big Stiffy 60-degree v-bit is, watch this YouTube video of a very large CNC router project completely carved in 11 minutes using the same size 120-degree V bit. The 60 deg grooving bit is designed to give you the exact same performance.

Why is it called the Big Stiffy? Overall, the bit body has more mass and has a slightly shorter shank. This little design modification on your 60 degree v-bit  keeps your bit stiffer during cuts, which gives you a 50% improvement in your surface finish. In other words, the potential for chatter is virtually eliminated.

This bit has a carbide blade brazed to a 4140 body.

Item SKU: BV-60

Specs

  • Shank: 1/4" (6.35mm)
  • Cut diameter: 0.75" (25mm)
  • Cut angle: 60 degrees
  • Length: 2.15" (52mm)
  • Flutes: 2
  • Flute length: 065"
  • Material: 100% tungsten-carbide tipped

Settings

  • Feed rate: 80 inches per minute
  • Plunge rate: 25 inches per minute
  • Speed(rpm): 14,000
  • Depth per pass: 0.250"
  • Stepover: 20%

For Vectric users, get the latest CNC router bit tool database by going to this page

For CNC’s with routers, refer to this PDF download feeds & speeds table

Get feeds and speeds in your shop by scanning this QR code with the IDC Woodcraft App

QR Code Image for 60 Degree V Grooving Bit for CNC Routers, 1/4 Shank

Customer Reviews

Based on 12 reviews
100%
(12)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
J
John S Mclaughlin
60 * V Bit

I’m going to have to get another one , I’m wearing this one out😂

N
Norman Johnson
Carving stars

Just used it to carve an assortment of stars and it did just fine.

S
Steven Moss
.25 shank, 60 degree V bit.

I just got my Longmill together. I used the 1.5 surfacing bit to surface the spoil board. The bit preformed very well. I will be using the 60 degree v bit on my first project. I will let you know how it dose

P
Paul Lenart
Great company! Great people! Great products!

Recently purchased another 60 Degree V Bit. The old one is still in use and has been used for multiple jobs. I run my bits using the downloaded IDC toolbase and have never had an issue with burning a bit or damaging a project. A guy can never have enough bits though, so i keep at least two of everything in the drawer!

G
Geoffrey Bell
Big Stiffy V-Bit

Woah! A bit of a specialist bit for specific jobs, bit just the ticket when needed. Runs true and cuts fast. The quality we have come do expect from IDC Woodcraft CNC bits. Very happy with this bit.
