3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3d tapered ball nose set to carve cnc router bit project
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
extreme detail 3d carving bit for CNC routers
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3d tapered ball nose set to carve cnc router bit project
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
extreme detail 3d carving bit for CNC routers
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit
3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit

3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit

Availability: Out Of Stock

$89.23 USD

Save $12 when you get this set of precision-engineered 3D carving taper ball nose bits and the BEAST by IDC Woodcraft.

The BEAST included in the set is designed to remove the most material possible in the least amount of time for those intricate and complex 3d roughing tool paths.

Put together, this set is designed to provide the highest level of detail on your 3D woodworking carves, enabling you to tackle any project, from delicate and intricate designs to larger, more complex 3D carvings.

Key Details

Feeds And Speeds

Reviews

Welcome to a combination of CNC router bits one needs for 3D carving on CNC routers. This set is for CNC woodworkers who want the exact CNC router bits to do 3D wood carving on their CNC routers.

At the heart of this set are the IDC Woodcraft fine detail and ultra-fine-detail taper ball nose bits. These precision-engineered solid carbide bits are the tools of choice for creators who expect clean results in their 3D carving projects.

This set also features the BEAST hyper-speed roughing endmill bit, a powerhouse when it comes to quickly eliminating excess material. After all, removing the rough material to get to the actual 3D carving quickly is what we want, and the BEAST is designed to do exactly that…and fast!

At  IDC Woodcraft, we strive to set the gold standard for producing high-quality router bits and exceptional customer service, and this set is no exception.

So, whether you're a seasoned pro or a newcomer looking to dive into the world of 3D carving, this CNC Router Bit Set is your ticket to precision, speed, and quality in your 3D carves on your CNC router.

Item SKU: 3D-BE-SET

Fine-Detail Taper Ball Nose Bit (TBN-1)

Specs: for this CNC router bit.

  • Shank: 1/4" (6.35mm)
  • Flutes: 2
  • Length: 2" (60mm)
  • Side-Angle: 10 degrees (full angle 20°)
  • Ball nose radius 0.045" (3/64) (1.14mm)
  • Material: Tungsten carbide

Settings

  • Feed rate: 60 inches per minute
  • Plunge rate: 25 inches per minute
  • Speed(rpm): 19,000
  • Depth per pass: 0.250"
  • Stepover: 6-8%

Fine-Detail Taper Ball Nose Bit (TBN-2)

  • Shank: 1/4" (6.35mm)
  • Flutes: 2
  • Length: 2.25" (60mm)
  • Side-Angle: 10 degrees (full angle 20°)
  • Ball nose radius 0.045" (3/64) (1.14mm)
  • Material: Tungsten carbide

Settings for your CNC router

  • Plunge rate: 20 ipm
  • Feed rate: 60-80 in/m (35-47mm/s)
  • Stepover: 6-8%
  • RPM: 14,000-18,000

The BEAST 1/4" Hyper Speed Roughing BIT (BEAST)

Settings

  • Feed rate: 100 inches per minute
  • Plunge rate: 80 inches per minute
  • Speed(rpm): 22,000
  • Depth per pass: Up to 0.750"
  • Stepover: 80%

Specs

  • Cut diameter: 1/4"
  • Shank: 1/4"
  • Length: 2.5"
  • Flutes: 3
  • Flute length: 1"
  • Material: 100% carbide

For Vectric users, get the latest CNC router bit tool database by going to this page

For CNC’s with routers, refer to this PDF download feeds & speeds table

Customer Reviews

Based on 14 reviews
100%
(14)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
B
Brian Nackers

3D Carving CNC Router Bit Set, 2 Fine detail Taper Ball Nose and The BEAST Roughing Bit

G
Gregory Dunkelberger
great bits

the beast, is a beast. and the tapered ball nose was just what i needed to get into tight spaces

K
Kevin Duke

Haven’t received them yet. I shipped them to my friend’s house.

D
David Braden
Great bits

Bought a couple of BN bits and they are perfect. Cuts and leaves a great finish. Thanks IDC. Won't shop elsewhere.

A
Angel Monge
Bits

Bits are great, but thought it would have some basic instruction on how to get this project going. Any recommendations on wood to use and rough estimate on how long the job would take. But never disappointed with the bits.
